CDHD-30/24 Marine Charging Power Description

WUHAN HANGDA ELECTRICAL SOURCE TECHNOLOGICAL CDHD-30/24 marine charging power is widely used on the ships for charge and discharge panel, this CDHD-30/24 charger output current is 30A, the output current and output voltage can be adjust according to your requirements.

Wuhan Hangda Electrical Source Technological CDHD-30/24 Marine Charging Power Technical Specifications

  • Origin:

    MADE IN CHINA
  • Market:

    China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
  • CDHD-30/24II:

    Input voltage single phase.
  • CDHD-30/24III:

    Input voltage three phase.
  • Serial Number:

    Please provide serial number for repair or replacement this CDHD-30/24 charger.
  • Input Voltage:

    AC110V, AC220V, AC380V, AC440V
  • Rated Frequency:

    50/60HZ
  • Output Voltage:

    DC24V
  • Current Adjust Range:

    5~30A
  • Protection:

    IP20, IP22
  • Multi Functions:

    Output over voltage alarm, output over current protect, over temperature protect.
  • Warning:

    Never charge a damaged battery.
  • Working Temperature:

    -10℃ ~ 50℃
  • HS Code:

    8504409999
  • Dimension:

    310 x 225 x 97 mm
  • Weight:

    6Kg
  • Lead Time:

    Stock Available.
  • Class Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
