Home > CHONGQING STARTING > CHONGQING 2103 Spring Starting Motor

CHONGQING 2103 Spring Starting Motor Description

Chongqing staring power unit PN2103 spring starting motor is widely used for henan HND TDB234V6 diesel engine as emergency spring starter.

CHONGQING STARTING POWER UNIT PN 2103 SPRING STARTING MOTOR Technical Specifications

  • Origin:

    Made In China
  • Market:

    China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
  • Features:

    reliablility, stability, powerful, long life, etc...
  • Starter PN NO.:

    2101, 2102, 2103, 2104, 2105, 2106, 2107, 2108, etc...
  • PN2103 Application:

    HENAN HND TDB234V6 diesel engine
  • Available Option:

    cummins 6C, QSB7, john deere 6068, weichai WP10, deutz BF6M1015, MWM TBD234 V6, V8, etc...
  • Spring Starter Step1:

    The starter can compress the springs and store high energy within the unit.
  • Spring Starter Step2:

    Release energy rapidly to start the engine.
  • Adaptability:

    Chongqing spring starting motor adapt to harsh working conditions, like explosion proof, wet, etc...
  • Mounting Flange:

    SAE standard 1, 2, 3
  • Engine Displacement:

    7.5 ~ 11L
  • HS Code:

    8536490090
  • Dimension:

    366 x 129 x 129 mm
  • Weight:

    25Kg
  • Lead Time:

    Stock Available.
  • Class Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
