OTN4A-1 Rudder Angle Indicator Description
Product Name:
OTN4A-1 Rudder Angle IndicatorModel No.:
OTN4A-1
JINZHOU OTN4A-1 rudder angle indicator is usually installed in the wheelhouse outdoor bridge wing of the ships to show the actual position of the boats rudder.
JINZHOU OTN4A-1 Rudder Angle Indicator Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Application:
shows rudder position of ships, installed in bridge, engine room, steering gear room -
Related Model:
OTN3A-1, OTN4A-1, OQF2D-1,OQF2E-1, OTY4A-1, OSD6A-1, OSD6B-1, etc... -
Angle Indicator Range:
port 40° to starboard 40° -
Mount Type:
wall mounting type -
Voltage:
AC220V, AC110V, DC24V -
Angel Indicator Size:
100mm, 130mm, 160mm, 200mm -
Lighting Dimmer:
with backlight dimmer -
Rudder Angle Indication:
we offers rudder angle incication systems like 4-20mA current loop system, ±10V system, CAN systems. -
Features:
outdoor bridge wing mounting, high vibration resistance, superior accuracy -
Protection:
IP56 -
HS Code:
8543709990 -
Dimension:
200x200x125mm -
Weight:
4Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
