Home > JINZHOU RUDDER ANGLE > OTY4D-1 Rudder Angle Indicator

OTY4D-1 Rudder Angle Indicator Description

JINZHOU OTY4D-1 rudder angle indicator is usually installed in the bridge, capatain room, engine control room of the ships to show the actual position of the boats rudder.

JINZHOU OTY4D-1 Rudder Angle Indicator Technical Specifications

  • Origin:

  • Market:

    China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
  • Application:

    shows rudder position of ships, installed in bridge, engine control room, capatain room
  • Related Model:

    OTY3A-1, OTY3C-1, OTY3D-1, OTY3E-1, OTY4A-1, OTY4B-1, OTY4C-1, OTY4D-1, OTY4E-1, etc...
  • Angle Indicator Range:

    port 40° to starboard 40°
  • Mount Type:

    wall mounting type
  • Voltage:

    AC220V, AC110V, DC24V
  • Angel Indicator Size:

    100mm, 130mm, 160mm, 200mm
  • Lighting Dimmer:

    with backlight dimmer
  • Rudder Angle Indication:

    we offers rudder angle incication systems like 4-20mA current loop system, ±10V system, CAN systems.
  • Features:

    complete and type approved system, high vibration resistance, superior accuracy
  • Protection:

  • HS Code:

  • Dimension:

  • Weight:

  • Lead Time:

    Stock Available.
  • Class Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
