Home > JIAXING KEXUN ELECTRON > KED12-S-Q Telegraph Repeater
KED12-S-Q Telegraph Repeater Description
Product Name:
KED12-S-Q Telegraph RepeaterModel No.:
KED12-S-Q
JIAXING KEXUN ELECTRON KED12-S-Q type marine main engine telegraph repeater, it is widely used on the ships for communicating orders of the propeller revolution and thrust direction from the navigating bridge to the position in the machinery space or the normal control position of propeller in the control room.
JIAXING KEXUN ELECTRON KED12-S-Q Type Marine Main Engine Telegraph Repeater Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Main Power:
DC24V -
Alarm Sound Level:
80dB ~ 90dB -
Mount:
Flush mount type. -
Passive Contact:
2A/30VDC, 1A/125VAC -
Operation Steps:
Ahead dead Slow, Ahead Slow, Ahead Half, Ahead Full, Stop, Finsh, Standby, Astern dead Slow, etc... -
Telegraph Function:
When transmitter and receiver are not synchronous, it will send out audible and visual alarm. -
Alarm:
Power failure alarm, fault alarm, error alarm. -
Interface:
With VDR interface. -
Color:
Black -
Protection:
IP20 -
HS Code:
8517699000 -
Dimension:
220x160x78mm -
Weight:
0.6Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
