F72-ZBK Insulation Monitor Description
Product Name:
F72-ZBK Insulation MonitorModel No.:
F72-ZBKΩ
Shanghai Yi Tai Instruments F72-ZBKΩ insulation monitor is widely used on the ships to monitoring the insulation resistance at the DC24V net work, alarm signal will generate if the resistance lower than the preset value.
SHANGHAI YI TAI INSTRUMENTS F72-ZBKΩ Insulation Monitor Technical Specifications
-
Origin:
Made In China -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Voltage:
DC24V -
Related Type:
F72-ZBKΩ, F96-ZBKΩ -
Scale Develop Angle:
90°, 240° -
Spare Parts:
Spare parts like external converter YT-BMΩ is available. -
Accuracy Class:
1.5 -
Measurement Range:
0~1MΩ, 0~5MΩ, 0~10MΩ -
Alarm Preset Value:
10kΩ, 30kΩ, 60kΩ, 100kΩ, 200kΩ, 500kΩ, 1MΩ -
Protection:
IP44, IP56 -
HS Code:
9030332000 -
Dimension:
72 x 72 x 120 mm -
Weight:
0.5Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
