Home > YUANWANG INSTRUMENT > UQK-01-C-B Float Level Controller

UQK-01-C-B Float Level Controller Description

JIANGSU YUANWANG INSTRUMENT UQK-01-C-B explosion proof float level controller is widely used on the ships to monitor the high levels and low levels for oil tanks in engine room, like heavy fuel oil tanks, settling tanks, sludge tanks, sewage tanks, fresh water tanks, lub oil tanks, D.O tanks and others.

JIANGSU YUANWANG INSTRUMENT UQK-01-C-B Float Level Controller Technical Specifications

  • Origin:

    Made In China
  • Market:

    China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
  • Self Test Device:

    The model UQK-01-C-B-Z with test device is available for option.
  • Material:

    Stainless Steel, Copper, Aluminium
  • Application:

    Oil Tank High Level Alarm, Oil Tank Low Level Alarm
  • Standard Flange Size:

    OD: 195mm, PCD: 160mm, Hole: 8x18mm
  • Other Flange Size:

    The UQK-01-C-B float level controller flange size can be made according to customers requirements.
  • Control Range:

    10 ~ 30 mm
  • Mounting Type:

    Horizontal Mounting, Vertical Mounting, Top Mounting
  • Float Ball:

    Φ50 , Φ60 , Φ76
  • Contact Capacity:

    250V , 10A
  • Protection:

    IP66 , IP68
  • Explosion Proof:

    The model UQK-01-C-B explosion proof grade is Exd IICT6.
  • Working Temperature:

    ≤ 120℃
  • HS Code:

  • Dimension:

    370 x 200 x 200 mm
  • Weight:

  • Lead Time:

    Stock Available.
  • Class Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
