UQK-03-C Float Level Controller Description

JIANGSU YUANWANG INSTRUMENT UQK-03-C float level controller is widely used on the ships to monitor the high levels and low levels for bilge oil tanks in engine room.

JIANGSU YUANWANG INSTRUMENT UQK-03-C Float Level Controller Technical Specifications

  • Origin:

    Made In China
  • Market:

    China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
  • Material:

    Stainless Steel, Copper, Aluminium
  • Application:

    Bilge Tank High Level Alarm
  • Standard Flange Size:

    OD: 120mm, PCD: 102mm, Hole: 6x12mm
  • Other Flange Size:

    The UQK-03-C float level controller flange size can be made according to customers requirements.
  • Control Range:

    8 ~ 1000 mm
  • Mounting Type:

    Vertical Mounting, Top Mounting
  • Float Ball:

    Φ50 , Φ60 , Φ76
  • Contact Capacity:

    250V , 10A
  • Protection:

    IP66 , IP68
  • Explosion Proof:

    The model UQK-03-C-B explosion proof grade Exd IICT6 is available for option.
  • Working Temperature:

    ≤ 120℃
  • HS Code:

    9026209000
  • Dimension:

    1500 x 150 x 150 mm
  • Weight:

    2Kg
  • Lead Time:

    Stock Available.
  • Class Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
