SCS-2460-430 KST Power Supply For Ship Description

Wuhan constant ship electric appliance SCS-2460-430 KST power supply for ship is widely used on the ships for charge and discharge panel as marine battery charger & battery rectifier.

WUHAN CONSTANT SHIP ELECTRIC APPLIANCE SCS-2460-430 KST POWER SUPPLY FOR SHIP Technical Specifications

  • Origin:

    MADE IN CHINA
  • Market:

    China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
  • SCS-2460-430 Voltage:

    input voltage three phase 440VAC
  • Green Indication:

    The working indicator light is on when the power supply is working normally.
  • Red Indication:

    The fault indicator light is on when the power supply has a fault or starts.
  • Output Rated Voltage:

    28.2VDC
  • Voltage Adjustment:

    output voltage adjustment range: 20~30VDC
  • Current Adjustment:

    output current adjustment range: 6 ~ 60A
  • Application:

    charge and discharge panel marine DC24V chargers
  • Overvoltage Protection:

    output overvoltage protection 30VDC
  • Undervoltage Alarm:

    output undervoltage alarm 21VDC
  • Overheat Protection:

    temperature inside the charger 85℃
  • Short Circuit Protection:

    the charger is free from damage after short circuit and automatically recovers after repair
  • Output Alarm:

    the output alarm relay resets in the case of charger fault
  • Heat Emission Method:

    air cooling fan
  • Protection:

    IP20, IP22
  • Working Temperature:

    -10℃ ~ 50℃
  • HS Code:

    8504409999
  • Dimension:

    310 x 190 x 90 mm
  • Weight:

    5Kg
  • Lead Time:

    stock available
  • Class Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
